Katool KT-H100 10,000 lb Two Post Car Lift for Garage & Commercial Use

Katool KT-H100 10,000 lb Two Post Vehicle Lift

The Katool KT-H100 Two Post Vehicle Lift is a commercial-grade automotive lift engineered for reliability, safety, and daily shop performance. With a 10,000 lb lifting capacity, this two-post car lift is ideal for professional automotive shops and serious home garages servicing cars, SUVs, and light-duty trucks.

Built from heavy-duty structural steel and CE approved and certified, the KT-H100 exceeds industry safety standards with 115% dynamic and 150% static load testing. Dual hydraulic chain-drive cylinders provide smooth, synchronized lifting, while the symmetric arm design ensures balanced vehicle positioning during service.

A manual safety release accessible from both sides allows safe and convenient operation. Included rubber door-opening protection pads, +30mm and +120mm extension adaptors, and feet-protection safety guardrails enhance both vehicle protection and technician safety. Designed to operate on standard 220V single-phase power, with optional 110V configuration, the KT-H100 delivers dependable performance in a wide range of garage setups.

Why Choose the Katool KT-H100 Two Post Lift

• 10,000 lb two post car lift for garage or shop use

• CE certified Katool automotive equipment

• Smooth, stable hydraulic lifting system

• Symmetric arm design for balanced vehicle support

• Dual-side manual safety release

• Ideal car hoist for garage applications

Important Note:
To ensure safe installation, the concrete thickness must be a minimum of 5.9" (150mm) with a 3000 PSI rating. Incorrect installation on improper concrete can result in serious injury or death. It is the customer’s responsibility to verify concrete thickness and strength before purchase and installation.

Key Features

• 10,000 lb Lifting Capacity (4,500 kg)
  Supports a wide range of passenger vehicles and light trucks

• CE Approved & Certified
  Tested to 115% dynamic and 150% static load standards

• Dual Hydraulic Chain-Drive Cylinders
  Smooth, synchronized lifting with long-term durability

• Symmetric Arm Design
  Maintains proper weight distribution during lifting

• Manual Safety Release (Both Sides)
  Easy and secure operation

• Extension Support Adaptor Sets
  Includes +30mm and +120mm adaptors for vehicle versatility

• Rubber Pad Door Opening Protection
  Prevents vehicle damage during lifting

• Feet-Protection Safety Guardrails with Tool Box
  Enhances technician safety and convenience

• Flexible Power Options
  220V / 60Hz / 1PH standard
  110V / 60Hz / 1PH optional

Specifications:

Technical Specifications

• Lifting Capacity: 10,000 lbs (4,500 kg)

• Max Lifting Height: 70.75" (1,800 mm)

• Min Height: 4.25" (110 mm)

• Overall Height: 110.25" (2,800 mm)

• Overall Width: 142.25" (3,614 mm)

• Outside Column Width: 128" (3,250 mm)

• Inside Column Width: 110.25" (2,800 mm)

• Drive-Thru Clearance: 94.5" (2,400 mm)

• Front Arm Reach: 30.75" – 50.5" (2-stage)

• Rear Arm Reach: 30.75" – 50.5" (2-stage)

• Motor: 220V / 60Hz / 1PH / 2.2 kW

• Net Weight: 1,256 lbs (570 kg)

Installation Requirement (MANDATORY)

Concrete must be at least 5.9 inches (150 mm) thick with a minimum 3,000 PSI rating.
Failure to meet these requirements may result in serious injury or death.
It is the customer’s responsibility to verify slab thickness and strength prior to installation.

Warranty

• 1-Year Limited Warranty on all parts and manufacturing defects

• 3-Year Structural Warranty on vehicle lift components

• Optional 2-Year Extended Warranty available

Warranty covers cylinders, motors, power units, electronics, and related components.
Labor is not included.

Additional Resources:

For further guidance, download the product manual:

• Download Manual (PDF)
