Summit 24" Wide 230V 4-Burner Radiant Cooktop - CREK4B

Summit 24" Wide 230V 4-Burner Radiant Cooktop - CREK4B

Summit offers an extensive selection of radiant cooktops for all kitchen spaces, including 24" wide European choices.

Made for us in France, the CREK4B is a 230V electric cooktop sized at 24 inches wide to bring full cooking capacity to smaller kitchen spaces. Two 7.5" elements offer 1800W of power for larger cooking vessels, with two standard 6" 1200 elements to handle lighter cooking needs.

The EuroKera glass surface comes in a striking jet black finish, with color-matched push-to-turn knobs to complete the look. The knobs are located towards the front of the cooktop, making them easier to access and preventing users from having to reach over hot burners. This unit includes individual indicator lights and residual heat indicators to ensure added safety when cooking.

This cooktop can also be ordered in white (CREK4W). Additional choices, including 2, 3, and 5-burner cooktops, can be found in Summit's extensive product line. Browse our website for our full selection.

NOTE: This unit requires professional installation and is designed for cutouts sized 22" W x 18 5/8" D.

Features

• 24" width: Designed to fit 22" W x 18.63" D cutouts
• EuroKera surface: Smooth ceramic glass cooking surface in a sleek black finish
• 2 High output burners: Front right and rear left burners are sized at 7" with 1800W of cooking power for larger pots and pans
• 2 Standard burners: Front left and rear right burners are sized at 6" with 1200W of cooking power to meet most heating needs
• Push-to-turn knobs: Controls require a gentle push to help prevent cooking accidents
• Indicator lights: Each burner includes an indicator light to show when the unit is on
• ADA Compliant: Front-located knobs meet ADA guidelines for accessibility
• 220-240V operation: Requires professional hardwired installation

Specifications

Overview

• Height of Cabinet: 3.0" (8 cm)
• Width: 24.0" (61 cm)
• Depth: 20.5" (52 cm)
• Cabinet: Black
• US Electrical Safety: UL
• Canadian Electrical Safety: ULC
• Amps: 25.0
• Voltage/Frequency: 230 V AC/60 Hz
• Weight: 18.0 lbs. (8 kg)
• Shipping Weight: 24.0 lbs. (11 kg)
• Parts & Labor Warranty: 1 Year
• UPC: 761101055510

Electric Cooktop

• Heating Type: Radiant
• Surface: Glass
• Element Type: Glasstop
• Number of Elements: 4
• Controls: Dial
• Countertop Cutout Height: 3.5" (9 cm)
• Countertop Cutout Width: 22.0" (56 cm)
• Countertop Cutout Depth: 18.63" (47 cm)
• Element #1 Size: 6.0" (15 cm)
• Element #1 Wattage: 1200.0
• Element #2 Size: 7.5" (19 cm)
• Element #2 Wattage: 1800.0
• Element #3 Size: 6.0" (15 cm)
• Element #3 Wattage: 1200.0
• Element #4 Size: 7.5" (19 cm)
• Element #4 Wattage: 1800.0
• Power Cord Included: No

Manufacturer Resources

• Brochure w/ Drawings
• Technical Drawing
• Other
• Use & Care

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
