Katool KT-X80 Pneumatic 8,000 LB Mid Rise Scissor Lift for Garage & Shop

Katool KT-X80 Pneumatic 8,000 LB Mid Rise Scissor Lift

The Katool KT-X80-PNEUMATIC Mid Rise Scissor Lift delivers professional-grade lifting performance with an 8,000 lb (3,500 kg) capacity, designed for automotive shops and home garages equipped with compressed air. CE approved and certified, this lift exceeds 115% dynamic and 150% static load testing standards, ensuring long-term safety, durability, and reliability.

This pneumatic mid rise scissor lift features a pneumatic safety release system for fast, dependable lock disengagement, making it ideal for high-volume service environments. The lift supports both mobile and fixed-mount installation, giving users flexibility for brake service, tire work, detailing, and undercar maintenance.

A 24V safe control system, height limit switch, and starting-up system design ensure smooth and controlled lifting from day one. Composite rubber lifting blocks protect vehicle contact points, while self-lubricated bushings and bearings reduce wear and maintenance requirements.

The drive-up ramp lock design extends the platform length to accommodate longer vehicles, and the included portable mobility kit allows easy repositioning within the workspace. Powered by a top-level hydraulic system and an aluminum motor with integrated cooling fan, the KT-X80-PNEUMATIC is built for consistent performance during extended operation.

⚠️ Note: This model requires a compressed air source for the pneumatic safety release. If compressed air is not available, the electric version is recommended.

Why Choose the Katool KT-X80 Pneumatic Scissor Lift

• 8,000 lb pneumatic scissor lift for cars, SUVs, and light trucks

• Fast pneumatic safety release for shop efficiency

• Compact mid rise scissor lift for garage use

• CE-certified automotive lift

• Mobile or fixed-mount flexibility

Key Features

• 8,000 lbs (3,500 kg) Lifting Capacity

• Pneumatic Safety Release (Compressed Air Required)

• CE Approved & Certified (115% dynamic / 150% static tested)

• Mobile or Fixed-Mount Design

• 24V Safe Control System

• Height Limit Switch for over-lift protection

• Composite Rubber Lifting Blocks Included

• Self-Lubricated Bushings & Bearings

• Drive-Up Ramp Lock Design for longer vehicles

• Portable Mobility Kit Included

• High-Quality Hydraulic System

• Aluminum Motor with Cooling Fan

• 110V / 220V, 60Hz, Single Phase Operation

Specifications

• Lifting Capacity: 8,000 lbs (3,500 kg)

• Max Lifting Height: 41.25" (1,050 mm)

• Min Height: 4.25" (110 mm)

• Platform Length: 56.25" (1,430 mm)

• Overall Length: 80" (2,036 mm)

• Platform Width: 19.5" (500 mm)

• Overall Width: 73.25" (1,860 mm)

• Motor: 110V / 220V AC, 60Hz, 1PH

• Net Weight: 1,213 lbs (550 kg)

Warranty

• 1-Year Limited Warranty on all parts and defects

• 3-Year Structural Warranty on lift frame components

• Optional 2-Year Extended Warranty available

Replacement parts ship free.
Labor is not included.

Resources

For detailed installation instructions, operating procedures, and safety information:
👉 [Download Manual (PDF)]

Need help choosing between pneumatic or electric?

Start a live chat or call us at (866) 412-1837.
