EKKO Lithium Pallet Jack 4000 lb Capacity W/ PinPad EP18JLi

Name: EKKO Lithium Pallet Jack 4000 lb Capacity W/ PinPad EP18JLi
Brand: EKKO
SKU: EP18JLI
Price: 2888.0 USD
Availability: InStock

EKKO | Authorized Dealer | SKU: EP18JLI

$2,888.00 - $2,888.00

$2,888.00

$2,888.00 - $2,888.00

$2,888.00

+ FREE SHIPPING

Availability:

In stock

Get A Quote

✓ Free Shipping - on most EKKO products
✓ Manufacturer Warranty Included - on all EKKO
✓ 0% Financing Available - EKKO + 0% APR, Applicable at Checkout
✓ In Stock - most orders leave the warehouse in 3-5 business days
✓ Questions? - Call ‪(866) 412-1837

Quantity

Want today's EKKO prices but not ready for delivery?

No problem! All orders receive special attention and in most cases we can hold items and begin processing at a later date! Please contact us for more details!

EKKO Lithium Pallet Jack 4000 lb Capacity W/ PinPad EP18JLi

The EKKO EP18JLI Lithium Iron Phosphate Electric Walkie Pallet Jack is designed with the versatility of a pallet jack with full power lifting and driving capabilities. It is ideal for loading and unloading trucks, loading docks, stock rooms, manufacturing floors and warehousing.

Made from high quality steel and components with durable quality drives to withstand any terrain, usage, impact and directional changes for the use of any application with confidence and assurance.

Lithium 24V Powered
Load Capacity 4000 lb
Fork Size 27x48
Raised Height 7.8"
Lowered Height 3.35"
Pinwheel Capability
Polyurethane Wheels
Ergonomic Handle and Controls
Steel Construction
Robotic Welding
Charger Included
(1) Lithium Iron Battery LiFePO4 Included 24V/40Ah
3 Years Limited Warranty
New with PinPad

Specifications and Details

Specification	Unit / Type	Value
Model		EP18JLIC
Drive type		Electric
Manner of operation		Walkie
Load Capacity	lbs	4000
Load Centre	in	23.6
Axle centre to fork face	in	37
Wheel Base	in	47.6
Tire material		PU
Driving wheel size	Φ×w (in)	Φ8.26×2.75
Bearing wheel size	Φ×w (in)	Φ3.15×2.36
Qty of wheel (Front/Rear)		1x / 2
Tread	in	21.06
Lifting Height	in	7.8
Handle height (operation)	in	30.5 / 43.9
Lowered fork height	in	3.35
Overall Length	in	61.81
Body Length	in	16.53
Overall Width	in	27
Fork Size (T / W / L)	in	1.97 / 5.9 / 48
Fork Width	in	27
Min. Ground clearance	in	1.38
Aisle width (pallet 39.37×47.24, crossways)	in	69.7
Aisle width (pallet 31.5×47.24, lengthways)	in	71.6
Turning Radius	in	53.7
Driving Speed (load/unload)	km/h	4.2 / 4.5
Maximum gradeability (load/unload)		5 / 10
Brake Type		Electromagnetic
Drive Motor	kW	0.75
Lift Motor	kW	0.8
Battery Type		Lithium LiFePO4 (24V / 40Ah)
Battery Weight (±5%)	lbs	26.4
Type of drive control		DC
Noise level	dB(A)	≤70
Service Weight (with battery)	lbs	319
