Overview

Among the most compact on the market, the Drolet Spark II N wood stove can heat an area of up to 1,200 sq. ft., with a heat output reaching up to 75,000 BTU/h. It is non-catalytic and EPA certified, with an emissions rate of 1.7 g/h. NexBurn technology ensures more complete combustion, supported by a combustion grid that promotes quick ignition and optimizes burn efficiency. A tertiary combustion zone further enhances heating performance.

The deeper firebox allows for greater ash accumulation, reducing maintenance frequency. The steel top is reinforced with a stainless steel heat shield for increased durability. Packaged in a rigid box, the unit is easy to transport and simple to assemble.

Includes: steel legs, rear heat deflector, ceramic glass, cast iron door with adjustable hinges, ash lip, air control, stainless steel heat shield.

Why Choose the Drolet Spark II N?

  • Burn time up to 5 hours — fewer reloads, steadier heat.
  • 17" log capacity with a 1.67 cu. ft. EPA loading firebox.
  • Self-cleaning airwash glass system for a clear, unobstructed view of the flames.
  • EPA 2020 certified — 1.7 g/h particulate emissions.
  • Proudly made in Quebec and the United States.
  • Limited lifetime warranty.
  • Certified for mobile home and alcove installation (mobile home requires fresh air intake).

Any installation must be done according to the data and drawings detailed in the owner's manual.

Specifications

Brand Drolet
Model DB03402 (Spark II N)
Alcove installation approved Yes
Mobile home approved Yes, with fresh air intake
Certified to applicable standards By an accredited laboratory (CAN/USA)
Overall Dimensions (W × H × D) 18 1/2" × 28 3/4" × 29 3/4"
Blower (CFM) Optional
Combustion technology Non-catalytic
Stainless-steel secondary-air system Yes
Flue outlet diameter 6"
Distance – flue center to back of unit 7 5/8"
Distance – flue center to side of unit 9 1/4"
Recommended chimney diameter 6"
Type of chimney CAN/ULC S629, UL 103 HT (2100°F)
Minimum chimney height 12'
Door type Single, glass with cast iron frame
Door opening size (W × H) 12" × 7 5/8"
Glass type Ceramic glass
Glass surface per door (W × H) 10 1/4" × 8 1/2"
Steel thickness – body 3/16"
Steel thickness – top 1/4"
Firebox size (W × H × D) 14 1/4" × 11 3/4" × 18 7/8"
Log positioning Loading over depth
Maximum log length 17"
Firebox lined with refractory bricks Yes
Baffle type High quality vermiculite
High-efficiency certified appliance Yes, EPA 2020 approved
Canadian Standard (emissions) CSA B415.1-10
USA Standard (emissions) EPA
Canadian Standard (safety) ULC S627
USA Standard (safety) UL 1482, UL 737
Warranty Limited lifetime
Shipping weight 244 lb (111 kg)
Approved as add-on to an existing furnace No

Performance

Fuel type Dry cordwood (16" recommended)
Heating area 250 – 1,200 ft²
Overall firebox volume 1.85 ft³
EPA loading volume 1.67 ft³
Maximum burn time 5 hours
Maximum heat output (dry cordwood) 75,000 BTU/h (21.98 kW)
Minimum overall heat output rate 18,782 BTU/h (5.50 kW)
Maximum overall heat output rate 71,262 BTU/h (20.88 kW)
Average overall efficiency (dry cordwood, HHV) 74%
Optimum efficiency 81%
Optimum heat transfer efficiency 78%
Average particulate emission rate 1.7 g/h
Average CO 1.3 g/min

Clearances

Location Single Wall Pipe Double Wall Pipe
Back wall 14" 8"
Side wall 24" 24"
Corner 16" 14"
Base of unit to ceiling 84" 84"

Clearances apply to both Canada and United States installations. See the installation manual for full details.

Installation Requirements (Important)

Before ordering, confirm your space accommodates the unit's 18 1/2" W × 28 3/4" H × 29 3/4" D footprint, the required wall/corner clearances above, and a minimum 12' chimney height with a 6" diameter flue (CAN/ULC S629 or UL 103 HT rated, 2100°F). Any installation must be done according to the data and drawings detailed in the owner's manual. Installation is the customer's responsibility — please review the manufacturer documents before purchase:

Warranty

Limited Lifetime Warranty covering defects in materials and workmanship under normal residential use. Labor is not included.

Bottom Line

A compact, high-output wood stove built for real heating performance — up to 75,000 BTU/h and 1,200 sq. ft. of coverage from a footprint under 19" wide. EPA 2020 certified, made in North America, backed by a limited lifetime warranty. A strong pick for anyone who wants serious heat without a bulky stove.
