Accucold 24" Wide Built-In Refrigerator-Freezer - CT66LWCSS

Accucold 24" Wide Built-In Refrigerator-Freezer - CT66LWCSS

Accucold by Summit Appliance offers a wide range of under-counter refrigeration for general purpose storage. The CT66JBI Series includes built-in under-counter refrigerator-freezers equipped with dual evaporator cooling for optimum storage conditions.

Sized with a 24" footprint, the CT66LWCSS can be used built-in under counters or freestanding. The interior offers over 5 cu.ft. of storage capacity. This model comes with a fully wrapped stainless steel cabinet and door. A curved towel bar handle completes the professional look and a factory installed front lock offers convenient security.

Inside, our unique dual evaporator system separately cools the refrigerator and freezer section to ensure proper storage temperature. Cycle defrost operation reduces user maintenance in the automatic defrost fresh food section, with static manual defrost operation in the freezer compartment. Door storage provides easy access for tall bottles and small condiments. Additional features include adjustable shelves, a clear crisper, and automatic interior lighting.

The CT66LWCSS has long proven itself to have one of the best temperature performance records in the industry. To see additional finish options on this unit, browse the full CT66WBI Series.

Note: This product is intended for a wide variety of basic storage applications. Storage of high-value vaccines, life science materials, and medical/clinical biologicals require a product offering tighter temperature control and/or alarms, monitoring, and backup.

Features

• Fully wrapped stainless steel cabinet and door: Durable construction with modern style
• Built-in capability: Make the best use of space by installing your refrigerator under the counter and flush with other cabinets
• Cycle defrost: This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
• Front-mounted lock: Keyed lock offers added security
• Thin-line design: Our unique 24" wide models offer full capacity in a slim fit
• Professional towel bar handle: Curved handle in brushed stainless steel offers a sturdy grip with professional elegance
• Dual evaporator: Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
• Interior light: Automatically illuminates when you open the door
• Adjustable thermostat: Dial thermostat located inside for easy temperature management
• Fruit and vegetable crisper: Get the longest life and best taste out of produce by storing it in a convenient slide drawer
• Adjustable shelves: Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
• Door storage: Keep tall bottles and condiments right on the door for convenient access
• Height Adjustable: Adjustable legs allow the unit to be sized from 33 1/2" to 34 3/4" high
• 100% CFC free: Environmentally friendly design without ozone-damaging chemicals
• CARB Compliant: Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Specifications

Overview

• Height of Cabinet: 33.25" (84 cm)
• Width: 23.75" (60 cm)
• Depth: 23.5" (60 cm)
• Depth with Handle: 25.63" (65 cm)
• Depth with door at 90°: 45.63" (116 cm)
• Capacity: 5.1 cu.ft. (144 L)
• Defrost Type: Cycle
• Door: Stainless Steel
• Cabinet: Stainless Steel
• US Electrical Safety: ETL
• Canadian Electrical Safety: ETL-C
• Amps: 1.4
• Voltage/Frequency: 115 V AC/60 Hz
• Weight: 100.0 lbs. (45 kg)
• Shipping Weight: 105.0 lbs. (48 kg)
• Parts & Labor Warranty: 1 Year
• Compressor Warranty: 5 Years
• UPC: 761101068923

Refrigerator-Freezer

• Door Swing: RHD
• Reversible: Factory Reversible
• Adjustable Shelves: Yes
• Crisper Qty: 1
• Crisper Finish: Transparent
• Crisper Cover: Glass
• Interior Light: Yes
• Refrigerator - Interior Height: 19.5" (50 cm)
• Refrigerator - Interior Width: 20.5" (52 cm)
• Refrigerator - Interior Depth: 17.0" (43 cm)
• Refrigerator - Shelf Type: Wire
• Refrigerator - Shelf Qty: 2
• Refrigerator - Full Door Shelves: 3
• Freezer - Interior Height: 5.0" (13 cm)
• Freezer - Interior Width: 19.0" (48 cm)
• Freezer - Interior Depth: 11.5" (29 cm)
• Thermostat Type: Dial
• Fan Type: Exterior
• Refrigerant Type: R600a
• Refrigerant Amount: 0.92 oz.
• High Side PSI: 180.0
• Low Side PSI: 80.0
• Level Legs: 4
• Compressor Step Height: 7.0" (18 cm)
• Compressor Step Width: 20.5" (52 cm)
• Compressor Step Depth: 5.0" (13 cm)

Available Upgrades

Exterior

• DL2B: Factory installed NIST calibrated digital data logger (DDL)
• TT: Installed thermometer
• PH: Probe Hole
• Legs to raise unit height
• CAS6 6" casters
• CAS3 3" casters
• Alarm
• Extra key
• SS Hinges
• SCD: Self-closing door
• ODA: Open door alarm
• LHD: Left hand door swing
• Latch for door
• SSK
• HG: Hospital grade cord
• Agion Door

Interior

• FCGP: Internal fan with gel packs
• FC: Internal Fan

Handle

• TBC Copper Towel Bar Handle Upgrade

Door

• STO: Step-To-Open Door Pedal

Manufacturer Resources

• Brochure w/ Drawings
• Technical Drawing (.dwg)
• Use and Care
