Home > Mrcool > MRCOOL DIY 36,000 BTU Ductless Mini-Split Heat Pump, DIY-36-HP-230B25
MRCOOL DIY 36,000 BTU Ductless Mini-Split Heat Pump, DIY-36-HP-230B25 - PrimeFair

MRCOOL DIY 36,000 BTU Ductless Mini-Split Heat Pump, DIY-36-HP-230B25

Mrcool  | Authorized Dealer  |  SKU: DIY-36-HP-230B25

$2,709.00 - $2,709.00
$2,709.00
$2,709.00 - $2,709.00
$2,709.00
+ FREE SHIPPING
Availability:
In stock

Get A Quote

✓ Free Shipping - on most Mrcool products
✓ Manufacturer Warranty Included - on all Mrcool
✓ 0% Financing Available - Mrcool + 0% APR, Applicable at Checkout
✓ In Stock - most orders leave the warehouse in 3-5 business days
✓ Questions? - Call ‪(866) 412-1837

Sq Footage: 1500
Want today's Mrcool prices but not ready for delivery?

No problem! All orders receive special attention and in most cases we can hold items and begin processing at a later date! Please contact us for more details!

MRCOOL DIY 36,000 BTU Ductless Mini-Split Heat Pump, DIY-36-HP-230B25

Introducing the MRCOOL DIY 3rd Gen 36k BTU 16 SEER Ductless Mini-Split Heat Pump. These are ductless mini-split heat pumps with enhanced WIFI engineered to make setup not only quick and easy, but the MRCOOL DIY 3rd Generation is flexible enough to be installed virtually anywhere without requiring specialized tools or expensive equipment.

The 36,000 BTU unit is 16 SEER and designed to heat and cool a single 1500 square foot room efficiently and our SmartHVAC app is compatible with Amazon Alexa and Google assistant. You can also control your DIY anywhere with your Apple or Android smart device with an Internet connection. Doing it yourself has never been easier with the new MRCOOL DIY. This unit is shipped in two boxes.

FEATURES:

  • Our Easy DIY installation: pre-charged quick connect line doesn't require special tools, equipment, or training
  • This bundle includes all the parts you'll need to install the unit and includes a 25 ft. line set
  • This bundle can heat or cool to one Air Handler for 1 Zone
  • SmartHVAC app: WIFI control - control your DIY anywhere with your Apple or Android smart device and an Internet connection
  • Variable-speed DC inverter compressor technology cuts operating costs
  • Low ambient cooling: cooling down to 5°F exterior temperatures? the ideal system for computer server rooms, greenhouses, and any other applications that require cooling all year
  • The unit is 16 SEER and designed to heat and cool a 1500 square foot space
  • 7-Year compressor warranty and 5-year parts warranty
  • Auto-restart: - power outage? No worries, the MRCOOL DIY E star Series auto-restart has the unit running again immediately
  • Gold Fin condenser: corrosion-resistant coastal living - don't worry, our condenser is built to resist long term corrosion
  • Louver position memory remembers so you don't need to - horizontal louver automatically moves to the same position you set the last time the unit was turned on
  • Automatic leakage detection technology to alert you should a problem arise

SPECIFICATION:

Product Dimensions 86.81"W x 27.24"D x 46.14"H
Product Weight 191.36 lbs.
Condenser Dimensions 37.24"W x 16.14"D x 31.89"H
Condenser Weight 150.35
Air Handler Dimensions 49.57"W x 11.10"D x 14.25"H
Air Handler     Weight 41.01 lbs
Freight Class 250
Mount Type Wall
Unit Type Mini-Split
SEER 16
EER 8.2
HSPF 8.9
CFM 823/588/411
Tonnage 3
Cooling Capacity 34,500 BTU
Heating Capacity 36,000 BTU
Color White
Decibel 35/45/52 dBA
Phase 1
Min Circuit Ampacity 25 A
Max Coverage Area 1500 sq ft
Zone Capacity 1
Refrigerant Type R-410A
Refrigerant Volume 119.9 oz
Air Flow Direction 4-Way
Speed 4
Min Ambient Heat 5 Degrees F
Electrical Requirements 208-230V / 60Hz / 30A
Line Set Length 16ft or 25ft
Max Lineset Length 164ft Max
Liquid Line Fitting 1/2 Inches
Liquid Line Size 3/8 Inches
Suction Line Fitting 3/4 Inches
Suction Line Size 5/8 Inches
Control Type LED
Condense Fan Motor RPM 600/750/85
Blower Motor RPM 750/950/12
Filter Type Washable
Oscillation Yes
Inverter Yes
Overload Protection Yes
Adjustable Thermometer Yes
Modes Quiet Mode
Fan Only
Auto Cool
Wifi Compatibility  Yes
App Compatibility  Yes
Compatible with: iOS
Android
Includes Remote Control
Batteries
Certifications CSA
Energy Star
AHRI
Registered Warranty 5-year Parts/7-year Compressor/1-year Remote
Contains Electronics Yes
Contains Chemicals Yes
Contains Aerosol Yes
Contains Compressed Gas Yes
Restricted States GU, PR, VI

PRODUCT MANUALS:

Installation Manual

Specifications Sheet

Technical Manual

Remote Control Manual

Warranty Document

Energy Guide

Accessory Manual
